Features of lead-free solder wire
|
|
|
|
Series
|
Model
|
Representative Composition
|
Fusion Temperature
|
Sn-Cu
|
Sn-0.7Cu
|
227
|
Low melting point,low Using temperature,strong antioxidant property and thermal fatugue resistance.The surface of solder joints is bright,solderwith glazed surface,mainly used for manual soldering and wave soldering
|
Sn-1.5Cu
|
227
|
Sn-3.0Cu
|
227-300
|
Low melting point,good fluidity,bright solder joints,and low cost,mainly used for manual soldering.
|
Sn-Cu-Ni-Ce
|
Sn-0.7Cu-0.1Ni-0.1Ce
|
227
|
Low melting point,good fluidity,bright solder joints,and low cost,mainly used for wave soldering.
|
Sn-Ag-Cu
|
Sn-3.8Ag-0.7Cu
|
217-219
|
Low melting point,good fluidity and invasive ability,good thermal fatigue resistance and highcost,mainly used for manual soldering and wave soldering.
|
Sn-3.0Ag-0.5Cu
|
217-220
|
Sn-0.3Ag-0.7Cu
|
217-227
|
Sn-Zn
|
Sn-9Zn
|
198-200
|
Melting point is close to Sn-Pb eutectic solder,but the wet ability and antioxidative effects are poor.
|
Sn-Sb
|
Sn-5Sb
|
240-243
|
High strength,good anti-oxidation property,and can inhibit effetively the gorwth of interface metal compounds and im poreve the solderability of solder joints,oftenused for manual soldering
|
Sn-In
|
Sn-52In
|
118
|
Sn-Bi
|
Sn-58Bi
|
138
|
The products have relatively good performance,but the creep property and tensile strength are poore,applicable to low temperature soldering of special process.
|
Sn-Zn-Bi
|
Sn-8Zn-3Bi
|
190-197
|
Sn
|
Sn-99.99
|
232
|
Mainly used for handicraft and electroplating process
|
